Drainage Pipe

Name: Drainage Pipe
Brand: XENON PIPES INDIA PRIVATE LIMITED
Price: 220.0 INR
Availability: InStock

Price 220.0 INR/ Piece

Get a Price/Quote

MOQ : 500 Pieces

Drainage Pipe Specification

Pressure
Up to 16 bar (varies by diameter and wall thickness)

Application
Drainage, sewage, waste water management, stormwater, agriculture, and infrastructure projects

Life Span
50 years (under standard conditions)

Feature
Corrosion resistant, leak-proof joints, lightweight, UV resistant, smooth inner surface, long service life

Product Type
HDPE Drainage Pipe

Material
Other

Shape
Round/Cylindrical

Standard
IS 4984, ISO 4427, DIN 8074/75

Connection Type
Socket fusion, butt fusion, electrofusion, or mechanical joints

Length
6 m or 12 m straight lengths (custom lengths available)

Thickness
2 mm to 58 mm (varies with diameter and pressure rating)

Diameter
63 mm to 630 mm (or as per requirement)

Weight
Varies by diameter and wall thickness (Check manufacturer specification)

Color
Black with blue stripes

Installation
Easy to fabricate, transport and install

Tensile Strength
Minimum 19 MPa

Surface Finish
Smooth Internal and External Surface

Elongation at Break
Minimum 350%

Resistance
High chemical and abrasion resistance

Usage Environment
Above and below ground installation

Flexibility
High flexibility, suitable for uneven ground

Temperature Range
-20C to +60C

Jointing Method
Heat fusion, compression fittings

Drainage Pipe About

HDPE (High-Density Polyethylene) Drainage Pipe is a high-performance piping solution designed for the safe transportation of stormwater, sewage, wastewater, and industrial effluents. Manufactured from premium-grade PE100 or PE80 material, HDPE drainage pipes offer excellent flexibility, high impact strength, superior chemical resistance, and long service life. They are ideal for underground drainage networks, municipal sewerage systems, industrial plants, and infrastructure projects.

Specifications

Parameter	Specification
Material	High-Density Polyethylene (HDPE) PE80 / PE100
Pipe Type	Smooth Wall / Corrugated (Single Wall or Double Wall)
Diameter Range	50 mm to 1200 mm OD (larger sizes available from some manufacturers)
Length	6 m, 12 m, or coil (small sizes)
Colour	Black, Black with Blue Stripes (application-specific)
Joint Type	Butt Fusion, Electrofusion, Coupler, Rubber Ring Joint (for corrugated pipes)
Pressure Rating	Non-pressure drainage or pressure-rated (PN 2.5 to PN 16) depending on application
Ring Stiffness	SN4, SN8, SN16 (for corrugated drainage pipes)
Operating Temperature	-40C to +60C (typical)
Standards	IS 14333, IS 4984, ISO 4427, EN 13476 (depending on pipe type and application)
Service Life	More than 50 years

Features

High impact and crush resistance
Excellent flexibility for ground movement
Corrosion and chemical resistant
Lightweight and easy to transport
Smooth inner bore for high flow efficiency
Leak-proof fusion joints
UV-stabilized black material
Low maintenance
Long service life

Applications

Underground drainage systems
Sewerage networks
Stormwater drainage
Industrial wastewater disposal
Municipal infrastructure
Highway and railway drainage
Residential and commercial drainage
Landfill leachate collection
Agricultural drainage

Exceptional Durability and Performance

Engineered for demanding environments, this drainage pipe delivers high resistance to chemicals, abrasion, and corrosion. Suitable for installations under diverse climate conditions-from -20C to +60C-its robust tensile properties and elongation ensure long-lasting service. Its UV resistance and leak-proof jointing add extra protection, making it the reliable choice for critical infrastructure and agricultural projects.

Effortless Installation and Versatile Application

Designed for easy fabrication, transport, and installation, this lightweight pipe system accommodates various above and below ground installations. It supports socket fusion, butt fusion, electrofusion, and mechanical joints, ensuring secure and adaptable connections. The pipe's flexibility and wide diameter range (63 mm to 630 mm) make it ideal for stormwater, sewage, and waste management systems as well as agricultural and infrastructure developments.

FAQ's of Drainage Pipe:

Q: How does the smooth internal and external surface benefit drainage operations?

A: The smooth internal and external surfaces minimize friction and reduce the risk of sediment buildup, ensuring efficient water flow and lowering maintenance needs over time.

Q: What is the recommended process for joining these pipes during installation?

A: You can securely join these pipes using heat fusion methods (such as socket fusion, butt fusion, or electrofusion) or with mechanical and compression fittings, ensuring strong, leak-proof connections.

Q: Where can this drainage pipe be installed?

A: It is suitable for both above and below ground installations, making it adaptable for drainage, sewage, wastewater management, stormwater handling, agriculture, and infrastructure projects.

Q: What makes this pipe suitable for harsh or chemical-rich environments?

A: Its high chemical and abrasion resistance, combined with corrosion resistance and leak-proof joints, allows it to perform reliably in demanding and aggressive conditions, including industrial sewage and agricultural runoff.

Q: When is it best to use this HDPE drainage pipe over other materials?

A: Choose this pipe when you require a long service life, resistance to chemicals, flexibility for uneven terrain, lightweight handling, and compatibility with modern installation and jointing technologies.

Q: How does the pipe's flexibility improve installation on uneven ground?

A: The pipe's high flexibility allows easy adjustments and bends without cracking or leaking, ensuring effective installation even on rough or undulating surfaces.

Q: What standards does this drainage pipe comply with?

A: This HDPE drainage pipe complies with IS 4984, ISO 4427, and DIN 8074/75 standards, affirming its suitability for domestic, agricultural, and municipal applications.
