Hdpe Service Saddle

Q: How is the HDPE Service Saddle installed on pipes?

A: The HDPE Service Saddle is designed for manual installation-simply position it over the pipe, align the saddle, insert the bolts, and tighten with a spanner. This straightforward process ensures a secure and leak-proof connection.

Q: What types of pipes and environments is the service saddle compatible with?

A: It is suitable for use on HDPE, MDPE, and certain LDPE pipes. The saddle can be installed both underground and above ground in water supply and irrigation environments, thanks to its corrosion and UV-resistant design.

Q: When should I use an HDPE Service Saddle?

A: Use this saddle when you need to create a branch connection on a main HDPE, MDPE, or compatible LDPE pipe-especially in potable water or irrigation systems where leak-proof and chemical-resistant fittings are essential.

Q: What are the main benefits of using this service saddle?

A: Key benefits include a long lifespan (up to 50 years), resistance to corrosion, chemicals and UV, leak-proof performance, and non-toxic materials safe for drinking water. Its robust design supports high pressures and is certified to IS 4984 and ISO 4427 standards.

Q: What temperature and pressure ranges can the saddle withstand?

A: The saddle can handle temperatures from -10C to 60C and pressures up to 16 bar (PN16), making it suitable for most water supply and irrigation applications.

Q: Is the service saddle safe for potable water use?

A: Yes, it is manufactured from non-toxic materials, including an EPDM rubber gasket and high-quality HDPE, ensuring safety and conformity for potable water supply.

Q: Can this saddle accommodate custom outlet sizes and main pipe diameters?

A: Absolutely. Standard outlet sizes are 1/2 inch, 3/4 inch, and 1 inch, but custom options are available upon request. It also fits a wide range of pipe diameters from 20mm to 315mm.
